OPERATING MANUAL
PROPERTIES OF THE DEVICE
The all-purpose meter is a digital measurement instrument designed to measure distinct electrical quantities. In case of certain meas-
urement quantities the meter adapts an adequate range depending on the result of the measurement. The meter is equipped with
measurement pincers, which permit to measure the intensity of alternating current in a single conductor with the inductive method.
Before using the meter, read the whole manual and keep it.
The meter has a plastic housing, a liquid crystal display and a measurement range switch. The housing is equipped with measurement
sockets and a transistor check socket. The meter is equipped with measurement cables with plugs. The meter is supplied without a
battery.
ATTENTION! The meter is not a measurement device as it is construed within the „Measurement Law”
TEHNICAL DATA
Display: LCD 3 1/2 digits – maximum displayed result: 1999
Sampling frequency: approximately 3 times per second
Overload signalling: „OL” symbol displayed
Polarization indication: „-” displayed before the result of the measurement
Maximum pincers opening: 37 mm
Maximum diameter of the pincers measurement conductor: 37 mm
Batteries: AAA; 2 x 1,5 V
Working temperature: 0 ÷ 40°C; at a relative humidity <75%
Storage temperature: -10°C ÷ +50°C; at a relative humidity <85%
External dimensions: 230 x 77 x 32 mm
Weight: approximately 220 g
ATTENTION! It is prohibited to measure electrical quantities exceeding the maximum measurement range of the meter.
Parameter
Direct voltage Alternating voltage Alternating current with pincers
R
IN
= 10 MΩ R
IN
= 10 MΩ; f
IN
= 40 ÷ 400 Hz f
IN
= 50 ÷ 60 Hz
Catalogue number Range Resolution Precision Range Resolution Precision Range Resolution Precision
YT-73091
200 mV 0,1 mV ±(0,8% + 3) 2 V 1 mV
±(1,2% + 5)
2 A 1 mA
≤ 0,4 A: ±(5% + 20)
> 0,4 A: ±(4% + 10)
2 V 1 mV
±(0,8% + 1)
20 V 10 mV 20 A 10 mA
≤ 4 A: ±(4% + 10)
> 4 A: ±(3% + 8)
20 V 10 mV 200 V 0,1 V 200 A 0,1 A
±(2,5% + 5)200 V 0,1 V
600 V 1,0 V ±(1,2% + 5) 600 A 1 A
600 V 1 V ±(1,0% + 5)
Remarks Overload protection: 600 V a.c. rms
Parameter Resistancea Diode tests Temperature
Catalogue number Range Resolution Range Range Range Range Resolution Precision
YT-73091
200 Ω 0,1 Ω ±(1,2% + 5)
I
F
= 1 mA U
R
= 1,48 V
-20
O
C ÷ +1000
O
C1
O
C
-20
O
C ÷ 0
O
C: ±(4% + 5)
0
O
C ÷ 400
O
C: ±(1% + 5)
400
O
C ÷ 1000
O
C: ±(2% + 10)
2 kΩ 1 Ω
±(1,0% + 5)20 kΩ 10 Ω
200 kΩ 0,1 kΩ
-4
O
F ÷ +1832
O
F1
O
F
-4
O
F ÷ +32
O
F: ±(4% + 9)
32
O
F ÷ 752
O
F: ±(1% + 9)
752
O
F ÷ 1832
O
F: ±(2% + 20)
2 MΩ 1 kΩ ±(1,2% + 5)
20 MΩ 10 kΩ ±(1,5% + 5)
Remarks Overload protection: 600 V a.c. rms
Precision: ± (% of the indication + weight of the least significant digit)
OPERATION OF THE MULTIMETER
ATTENTION! In order to protect from electric shock before the housing of the device is opened, disconnect the measurement cables
and turn the meter off.
Safety instructions
Do not operate the meter in the presence of an excessive humidity, toxic or inflammable vapours and in explosive atmosphere. Before
