YBIKE EVOLVE - Assembly Guide; Seat and Handlebar Assembly

Loosen the seat clamp. Insert the
seat post (No. 13) into the frame
2
6
ASSEMBLY INSTRUCTIONS
1. Seat and Handlebar Assembly
(No. 2) until the metal push pin clicks into position into one of the 2 holes provided, to suit
your child. The 2 holes are there to adjust into different seat heights. Close the clamp.
Place the front of the frame (No. 2) with handle steering caps (No.3) on top and under-
neath the frame, as in the picture above, and place this into the space provided on the
handlebar (No. 1). Use the Allen keys (No.12) to secure into position with the flat bolt
head (No.6) from below and handlebar bolt (No. 8) at the top, as in the picture above.
Push pin
3
Seat post
13
2
Seat clamp
3
3
8
1
