Yealink EHS60 - Package Contents; Connect the IP Phone and Headset; Cisco IP Phone Connection

1
2
Package Contents
Verpackungsinhalt | Contenido de la caja | Contenu de la boîte
User Guide
Bedienungsanleitung
Guía del usuario
Guide d'utilisateur
EHS60
RJ9 (4 pins) to RJ9 (4 pins)
RJ9 (4 pins) to RJ9 (4 pins)
& RJ45 (8 pins) to RJ12 (6 pins)
5 pin to RJ45 (8 pins)
Cable A
Cable B
Cable C
Connect the IP Phone and Headset
Anschluss von IP-Telefon und Headset |
Conecte el teléfono IP y los auriculares |
Connectez le téléphone IP et le casque
A
EHS60
RJ12 (6 pins)
RJ9 (4 pins)
Cisco IP Phone | Cisco IP-Telefon | Teléfono Cisco IP | Téléphone IP Cisco
Yealink
WH62/
WH63
Cable B
Phone
port
Note: You need to enable EHS feature for the phone extension on the server
side. The configuration item is Wireless Headset Hookswitch Control
Enabled.
