Yealink T30 Quick Installation Guide

T31P/T31G/T31/T30P/T30
:
Screw position
Max:4.5mm
(0.177”)
Max:8mm
(0.315”)
Min:6.5mm
(0.256”)
Screw position
x 2
100mm
100mm
85mm
85mm
124mm
100mm
T33G/T33P
:
Yealink provides the wall mount drilling templates, which locate and mark
the position for mounting the screws (not provided) on the wall, as shown
below:
Yealink liefert die Bohrschablonen für die Wandmontage, welche die Position für die
Befestigung der Schrauben (nicht mitgeliefert) an der Wand orten und markieren, wie
unten dargestellt:
Yealink proporciona las plantillas de perforación para montaje en pared, que ubican y
marcan la posición para montar los tornillos (no incluidos) en mural, como se muestra
a continuación:
Yealink fournit les gabarits de perçage pour le montage mural, qui permettent de
localiser et de marquer la position des vis (non fournies) sur le mur, comme indiqué
ci-dessous :
Mounting the Screws
1
Befestigung der Schrauben | Tornillos de montaje | Fixer les vis

Yealink T30 Specifications

General

PoE	No
Audio Features	HD Voice, Full-duplex speakerphone
Wall Mountable	Yes
Network	10/100M Ethernet
Local Phonebook	1000 entries
Display	2.3" 132x64-pixel graphical LCD
Ports	2 x RJ45 Ethernet ports
