Yekbee Keyboard Case User Manual

3
Installation and Removal
Function Keys
(1)
(2)
(3) (4)
1) Removing back protective piece: hold iPad on both sides and use thumbs to
gently push off the back cover (see photo.) Cover is held in place by two tabs.
2) Proceed to “peel” cover away from iPad.
3) Take iPad out.
4) Take iPad out upwards.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
8. Backward
9. Pause/Play
10. Forward
11. Mute/Unmute
12. Volume Down
13. Volume Up
14. Lock iPad.
1. Home Screen
2. Brightness Down
3. Brightness Up
4. Virtual Keyboard
5. Search
6. Copy
7. Paste

Yekbee Keyboard Case Specifications

Power

operating voltage	3.7 V DC
operation current	< 5 mA
standby current	1.0 mA

Battery

battery life	100++ working hours
standby mode	up to 300 days
sleep current	< 0.1 mA

Other Specifications

transmit range	up to 10 m
backlight colors	7 different colors
backlight brightness levels	three levels (low, medium, high)
