YG125-23 Maintenance ManualElectrical starting control system
141
17Electrical starting control system
Overview
The information display system displays the dynamic and static information of the complete vehicle on the instrument
panel for the driver’s safe operation.
The complete vehicle information theYG125-23displays include: vehicle speed, engine speed, fuel indicator, Neutral
indicator, turn indication,high-beam indication, total / subtotal mileage traveled and EFI Indicator.
Constituting parts and components include:
Combination meter
Turn lamp
Vehicle speed sensor
Fuel level sensor
Shift position switch
Signal switch
ECU
Circuit schematic drawing
Overview
Major parts and components
Circuit schematic drawing
Major faults diagnosis
