Yoder Smokers YS 480 User Manual

33
480 COOKING COMPONENTS
ITEM # PART # DESCRIPTION QTY.
1 90737
HINGE, STAINLESS
2
2 1024X12FHMSSS
FLATHEAD MACHINE SCREW, STAINLESS
8
3 1024WHN
12-24 WHIZ NUT
8
4 22860
SERIAL NUMBER TAG
1
5 236-2489-02
POP RIVET
4
6 W90796
480 DOOR
1
7 41435
HANDLE, ROD
1
8 22866
HANDLE, SPRING
1
9 22924
PUSH CAP, 3/8”
2
10 90901
UNIVERSAL CHROME COOKING GRATE, 8”
3
11 90558
HEAT DIFFUSER
1
12 W90386
480 SECOND SHELF
1
13 90377
THUMBSCREW, 5/16-18 X 3/4
1
14 W90067
CHIMNEY
1
15 1420X12SHCS
SOCKET HEAD SCREW, 1/4-20X1/2
1
16 1420WHN
NUT, WHIZ, 1/4-20
3
17 90117FLP
HOPPER MOUNTING BRACKET
1
18 1420X58WHB
BOTL, WHIZ, 1/4-20 X 5/8” LONG
2
19 90460
BUCKET
1
20 W90794
SMOKE CHAMBER
1
21 90896
SIDE SHELF
1
22 90894
FRONT SHELF
1
23 90352
LEFT ANGLE 2ND SHELF
1
24 90353
RIGHT ANGLE 2ND SHELF
1
