Yoder Smokers YS 480 User Manual

38
ITEM # PART # DESCRIPTION QTY.
1 90674
2 INCH CASTER WHEEL, 3/8-16
2
2 1420WHN
NUT, WHIZ, 1/4-20
16
3 3816WHN
NUT, WHIZ, 3/8-16
2
4 1420X58WHB
BOLT, WHIZ, 1/4-20 X 5/8” LONG
16
5 90260
PIN
2
6 90659
AXLE
2
7 10X34HHSDS
SCREW, HEX HEAD, SELF DRILLING, 10 X 3/4
16
8 90093LFP
BOTTOM SHELF
1
9 90089LF
RIGHT FRONT LEG
1
10 90088LF
LEFT FRONT LEG
1
11 90409
WHEEL
2
12 90092LFP
SKIRT, LONG, UNDERCARRIAGE
2
13 90165LFP
SKIRT, SHORT, UNDERCARRIAGE WITH LOGO
2
14 90087LF
REAR LEG
2
480 CART
