HOPPER ASSEMBLY
ITEM # PART # DESCRIPTION QTY.
1 90101
BODY, FRONT, FEED COMPARTMENT
1
2 90102
BULKHEAD, MOUNT, HOPPER
1
3 90106
COVER, END, FEED COMPARTMENT
1
4 W90791
HOPPER, PELLET SMOKER
1
5 90022
BUSHING, AUGER
1
6 90023
BUSHING, AUGER
1
7 W90019
AUGER
1
8 90027
PLATE, ANTI-TORQUE
1
9 90899
MOTOR, PELLET AUGER
1
10 90060
OUTER FAN, 68CMF
1
11 1420X12SHCS
SOCKET HEAD CAP SCREW, 1/4-20 X 0.05 LONG
2
12 10X34HHSDS
SCREW, HEX HEAD, SELF DRILLING 10 X 3/4
37
13 A90152
CONTROLLER
1
14 516X12SHSB
SCREW, SHOULDER, .313 X .50, SOCKET HEAD 1/4-20
1
15 51618X12SHSS
SCREW, SET, SOCKET HEAD, 5/16-18 X 1/2
1
16 1024X12HHSTS
SCREW, SLOTTED, HEX HEAD, SELF TAPPING, 10-24 X 1/2
4
17 22866
HANDLE, SPRING
1
18 1420WHN
NUT, WHIZ, 1/4-20
1
19 W90790
HOPPER BACK
1
20 W90788
HOPPER DOOR
1
21 90312
SOCKET, 15 AMP
1
22 632X38MS
SCREW, MACHINE, ROUND HEAD, 6-32 X 3/8 LONG
4
23 632HN
NUT, HEX, 6-32
4
24 832HN
NUT, HEX, 8-32
4
25 90413
FUSE, 5A
1
26 90412
FUSE HOLDER
1
27 W90553
FAN HOUSING
1
28 832X12MS
SCREW, MACHINE, PHILLIPS HEAD, 8-32 X 1/2 LONG
4
29 90686
INNER FAN, 115 CMF
1
30 90893
PLATE, FAN AIR DIVERTER
1
31 23985
VELCRO
1
32 90313
POWER CORD
1
33 W90026
IGNITER TUBE
1
34 A90494
IGNITER ASSEMBLY
1
35 1420X14SHSS
SCREW, SET, SOCKET HEAD, 1/4-20 X 1/4
4
