YOELEO FRAMESET R11 - Page 4

Frameset User Manual
Top cap
Headset bearings
Compression plug
Spacer (10mm)
Spacer (10mm)
Spacer (5mm)
Bearing cover
(10mm)
Split ring
Fork
Handlebar
Stem bolt
Stem bolts nut
Headset Bearing Installation
Please route the cable housing FIRST before install the bearings.
Lightly grease the contact point between metal and carbon surface.
Frame
8
7
6
1
2
3
4
4
4
5
6Nm
