Frameset User Manual
Spacer (10mm)
Spacer (10mm)
Spacer (5mm)
Bearing cover
(10mm)
Split ring
Spacers Installation
Handlebar Internal Routing
Route housing to the Lever from
this hole.
Pick the right spacer height to adjust your riding position. Remember to route the housing
inside bearing cover ring before routing inside the handlebar.
7
4
4
4
5
Top Cap Bolt Tightening
Eliminate play in the steering
tube by tightening top cap bolt.
Top cap
1
Compression Plug
Put the compression plug into
the steerer tube.
Compression plug
6
9Nm
