3
2. Specifications
2-1 General Specifications
Function: DC Voltage, AC Voltage, DC Current, AC Current,
Resistance, Frequency, Temperature, Capacitor,
Duty cycle ratio, Decibel (dB), Averaging functuon,
Relative values from the reference measurement
values (REL ), Minimum value (MIN), Maximum
value (MAX), Average value (AVG), Range Hold
(R•H), Data Hold (D•H), Auto Hold (A•H), Peak
Hold* (P•H), Continuity Check, Zero Adjustment
(Capacitor, Resistance), Diode Test, Save to
Memory, LCD backlight*,
*: For model 734 02 only
Measuring method: Σ modulation
Display: 5-digit (LCD)
Maximum Reading: 50000
Polarity Indicator: “–” Appears automatically when
the polarity is negative
Overrange Indicator: “ OL ”
Low-battery Indicator: “ ” Appears when the
batteries become low
Measurement cycle: Digital display 3 times per second
When frequency measurement: one times per second
When capacitor measurement (50mF): max. 0.03
time per second
Bar graph display 10 times per second
