YOKOGAWA 734 02 User Manual

24
Note
Optional Temperature probe is required for temperature measurement.
Temperature Probe: Thermocouple Type K
Model: 7511 02 to 05
1) Turn the function switch to the “ TEMP ” position.
2) Plug the black terminal of measuring probe into the “ COM ” input terminal
and the red terminal of measuring probe into the “ • V • Ω • •
TEMP ” input terminal.
3) Contact the measuring probe to the under test and then read the value
when it stabilizes.
To switch temperature units
Displaying “ ºC ” only is configured at factory before shipment. Carry out
the following setting procedure to display “ ºF ”. While pressing the
SELECT, RANGE and HOLD key simultaneously, turn the function
switch to the “ TEMP ” position. Next time pressing the SELECT key,
the temperature unit switches from ºC to ºF.
● Current Measurement (µA/mA/A)
WARNING
To avoid damage to instrument or equipment
Before starting measurement, make sure that the position of function switch
and the input terminals for connecting the testing leads are appropriate for
the desired mode of measurement.
1) Turn the function switch to the “µA ” , “mA ” or “A ”position.
(If the magnitude of the current being measured is not known, select the
“A ”position. Make sure the current being measured is no more than 0.5A
before the “µA ” or “mA ” position is selected.)
