YOKOGAWA 734 02 User Manual

25
2) Please select between DC and AC. When selecting AC, press the SELECT
key.
3) Plug the black testing lead into the “ COM ” input terminal and the red
testing lead into the “A ”input terminal.
If the current is in the order of mA or less, plug the red testing lead into the
“µA • mA” input terminal.
4) Connect the testing leads to the circuit under test and then read
the value when it stabilizes.
● DC+AC Current Measurement ( + )
WARNING
To avoid damage to instrument or equipment
Before starting measurement, make sure that the position of function switch
and the input terminals for connecting the testing leads are appropriate for
the desired mode of measurement.
1) Turn the function switch to the “µA” , “mA” or “A” position.
(If the magnitude of the current being measured is not known, select the
“A” position. Make sure the current being measured is no more than 0.5A
before the “µA” or “mA” position is selected.)
2) Press the SELECT key to select the DC +AC measurement.
(The display shows the + symbol.)
Plug the black testing lead into the “ COM ” input terminal and
the red testing lead into the “A” input terminal.
If the current is in the order of mA or less, plug the red testing lead
into the “µA • mA” input terminal.
3) Connect the testing leads to the circuit under test and then read the value
when it stabilizes.
