YOKOGAWA 734 02 User Manual

26
● Capacitor Measurement ( )
CAUTION
To avoid damage to instrument
• Turn off the power to the circuit under test before starting measurement in
order to prevent any excessive voltage from being applied to the instrument.
• Before starting measurement, be sure to discharge the capacitor under
check.
1) Turn the function switch to the “ ”position.
2) Plug the black testing lead into the “ COM ” input terminal and
the red testing lead into the “ • V • Ω • • TEMP ” input terminal.
3) Open the testing lead and press the SELECT key in 5nF range to adjust
the capacitance to zero. (The display shows “ 0.000 ”.)
4) Connect the testing leads to the circuit under test and then read the value
when it stabilizes.
Note
When the capacitor check is below the capacity at zero calibration,
“0.00” is displayed until the power off.
● Frequency Measurement (Hz), Duty cycle ratio (Hz)
CAUTION
To avoid damage to instrument
Turn off the power to the circuit under test before starting measurement in
order to prevent any excessive voltage from being applied to the instrument.
