28
● PEAK HOLD Function
This instrument can always detect, update and display the peak value
(instantaneous) in DCV and DCA measurement. The peak value of the wave
can be seen.
1) Turn the function switch to DCV or DCA position.
2) Connect the testing leads to the circuit under test.
3)Press the HOLD key to select Peak Hold. (The display shows the “ P•H ”
symbol.)
4) The display shows the peak value.
5) When resetting the peak value in HOLD, press the MIN/MAX key.
Then new peak value can be in HOLD.
Note
Even though the input signals (DCV, DCA) have negative polarity,
the peak value can be measured when the peak is in the positive direction.
1) Press the REL /% key to relative calculation in PEAK HOLD mode.
The display shows the “ ” symbol and the relative peak value.
2) Press the REL /% key to percentage calculation.
The display shows the “ % ” symbol and the percentage peak value.
SEE ALSO
Next section “ Relative and percentage calculation”
When resetting the peak value, press the MIN/MAX key.
Then new peak value can be in HOLD.
To cancel the percentage calculation, Press the REL /% key again.
“ % ” symbol disappears, then retrieves the PEAK HOLD mode.
