66 IM 04L41B01-02E
Timer, Event action > Timer
Setup Item Selectable Range or Selections Default Value Setting
Timer No. 1/2/3/4 1
Mode Off/Relative/Absolute Off
Relative > Interval 00:01 to 24:00 01:00
Relative > Reset at Math Start On/Off On
Absolute > Interval 1min/2min/3min/4min/5min/6min/10min/ 1h
12min/15min/20min/30min/1h/2h/3h/4h/
6h/8h/12h/24h
Absolute > Ref.time 0 to 23 0:00
Timer, Event action > Match time timer
Setup Item Selectable Range or Selections Default Value Setting
Timer number 1/2/3/4 1
Kind Off/Day/Week/Month Off
Day 1 to 28 1
Day of the week SUN/MON/TUE/WED/THU/FRI/SAT SUN
Hour 00:00 to 23:59 00:00
Timer action Single/Repeat Repeat
Timer, Event action > Event action
Setup Item Selectable Range or Selections Default Value Setting
Logic box number 1/2/3/.../39/40 1
Event None/Remote/Relay/Switch/Timer/ None
Matchtime/Alarm/UserKey
Remote > Remote number 1/2/3/4/5/6/7/8 1
Relay > Relay number I01/I02/.../I06 (Depends on the model.) I01
Switch > Switch No. S01/S02/S03/.../S29/S30 S01
Timer > Timer No. 1/2/3/4 1
MatchTimeTimer > Match Time Timer No. 1/2/3/4 1
Action MemoryStart/Stop/MemoryStart/MemoryStop/
DisplayGroupChange
Trigger/AlarmACK/MathStart/Stop/MathStart/
MathStop/MathReset/SaveDisplay/SaveEvent/
Message/Snapshot/DisplayRate1/2/ManualSample/
TimerReset/DisplayGroupChange/Flag/PanelLoad/
Time adjust
Message > Message No. 1 to 100 1
Message > Write to All/Select All
Message > Group number 1/2/3/.../35/36 1
Group > Group number 1/2/3/4/5/6/7/8/9/10 1
Flag > Flag number 1/2/3/4/5/6/7/8 1
TimerReset > Timer No. 1/2/3/4 1
PanelLoad> Setting file number 1/2/3 1
Setup Items and Default Values
