YOKOGAWA WT230 User Manual

1-7
IM 760401-01E
Functional Overview and Digital Display
1
(Display C)
1.
CURRENT
2.
For option /EX1
(Display C)
For option /EX2
(Display C)
2.
2.
When the crest factor is set to 6
Filter/Scaling/Averaging/External Sensor Input/Initializing set-up parameters
(Display C)
SETUP
1.
2.
(Set the external sensor input)
(Set averaging)
(Set the frequency filter)
(Set the line filter)
(Set scaling)
(Select the computation item)
(Select the measurement synchronization source)
(Select the number of displayed digits)
(Select the crest factor)
(Initialize the setup parameters)
(Select the display update rate)
Integration Setting
1.
SHIFT
RESET
INTEG SET
(Display C)
2.
(Set the integration mode)
(Set the integration timer)
(Set the rated integration time)
Turning the Harmonic Measurement Function ON/OFF
1.
SHIFT
START
HARMONICS
(Display C)
2.
(Set OFF)
(Set ON)
(Sets the target element (WT230 only))
(Set the PLL source)
(Select the computation method of harmonic distortion)
Storing/Recalling to/from Internal Memory
1.
SHIFT
STOP
MEMORY
( Display C )
2.
(Set measured data storage)
(Set measured data recall)
(Set setup parameter storage)
(Set setup parameter recall)
1.3 Digital Numbers and Characters and Initial Menus
