Physical and Electrical Data - 1 Phase
MODEL DRCS0181BE DRCS0241BE DRCS0301BE DRCS0361BE DRCS0421BE DRCS0481BE DRCS0601BF
Unit Supply Voltage 208/230 – 1 – 60
Normal Voltage Range 187 to 252
Minimum Circuit Ampacity
1
10.1 14.1 16.5 19.7 26.2 28.5 37.5
Max. Overcurrent Device Amps
2
15 25 25 30 45 50 60
Compressor Type
3
Recip Inertia Recip Recip
Scroll
B
Recip
Scroll
B
Compressor Amps
Rated Load 7.7 10.9 12.8 14.7 19.9 21.8 28.8
Locked Rotor 48 60 68 82 115 105 145
Crankcase Heater No No No Yes No No No
Fan Motor Amps Rated Load 0.5 0.5 0.5 1.3 1.3 1.3 1.5
Fan Diameter Inches 18 18 22 22 22 22 22
Fan Motor
Rated HP 1/12 1/12 1/15 1/4 1/4 1/4 1/4
Nominal RPM 1,100 1,100 850 850 850 850 850
Nominal CFM 2,000 2,000 2,300 3,300 3,300 3,300 3,450
Coil
Face Area Sq. Ft. 12.58 12.58 15.72 15.72 17.03 19.65 23.58
Rows Deep 1 1 1 1 1 1 1
Fin / Inches 18 18 18 18 18 18 22
Liquid Line OD 3/8 3/8 3/8 3/8 3/8 3/8 3/8
Vapor Line OD 3/4 3/4 3/4 3/4 7/8 7/8 1-1/8
Unit Charge (Lbs. - Oz.)
4
4 - 9 4 - 7 5 - 8 5 - 3 6 - 13 7 - 7 8 - 15
Charge Per Foot, Oz. 0.68 0.68 0.68 0.68 0.70 0.70 0.76
Operating Weight Lbs. 144 146 156 161 157 190 198
PHYSICAL AND ELECTRICAL DATA - 3 Phase
MODEL HABC-T036S HABC-T048S HABC-T060S HABC-W036S HABC-W048S HABC-W060S
Unit Supply Voltage 208/230 – 3 – 60
460 - 3 - 60
Normal Voltage Range
1
187 to 252 432 to 504
Minimum Circuit Ampacity 13.3 18.9 22.9
7.6 9.6 12.0
Max. Overcurrent Device Amps
2
20 30 40 15 15 20
Compressor Type Inertia Inertia Scroll
Inertia Inertia Scroll
Compressor Amps
Rated Load 9.6 14.1 17.3
5.4 7.0 9.0
Locked Rotor 78.0 130.0 123.0
40.0 64.0 62.0
Crankcase Heater No No No
No No No
Fan Motor Amps Rated Load 1.3 1.3 1.3
0.8 0.8 0.8
Fan Diameter Inches 22 22 22
22 22 22
Fan Motor
Rated HP 1/4 1/4 1/4
1/4 1/4 1/4
Nominal RPM 850 850 850
850 850 850
Nominal CFM 3,300 3,300 3,400
3,300 3,300 3,400
Coil
Face Area Sq. Ft. 15.72 17.03 23.58
15.72 17.03 23.58
Rows Deep 1 1 1
111
Fin / Inches 18 18 18
18 18 18
Liquid Line OD 3/8 3/8 3/8
3/8 3/8 3/8
Vapor Line OD 3/4 7/8 1-1/8
3/4 7/8 1-1/8
Unit Charge (Lbs. - Oz.)
4
6 - 2 7 - 10 9 - 3 6 - 2 7 - 10 9 - 3
Charge Per Foot, Oz. 0.68 0.70 0.76
0.68 0.70 0.76
Operating Weight Lbs. 157 184 198
157 184 198
1. Rated in accordance with ARI Standard 110, utilization range “A”.
2. Dual element fuses or HACR circuit breaker.
3. All scrolls listed with a superscript “B” are Bristol scrolls. All scrolls listed with a superscript “C” are Copeland scrolls.
4. The Unit Charge is correct for the outdoor unit, matched indoor coil and 15 feet of refrigerant tubing. For tubing lengths other than 15 feet, add or sub-
tract the amount of refrigerant, using the difference in length multiplied by the per foot value.
