Unitary Products Group 25
Multipliers for determining the performance with other indoor sections.
HEATING PERFORMANCE DATA
CONDENSING UNIT MODEL NO EABD-F018S
EVAPORATOR COIL MODEL NO FC/MC/PC/UC18
AIR TEMP.
ENTERING
OUTDOOR UNIT
AIR TEMP.
ENTERING
INDOOR COIL
ID CFM
450 600 750
MBTUH KW C.O.P. MBTUH KW C.O.P. MBTUH KW C.O.P.
60
60 20.9 1.5 4.1 21.7 0.7 8.8 22.5 1.4 4.6
70 19.9 1.5 3.8 20.7 1.1 6.3 21.6 1.5 4.3
80 18.8 1.6 3.5 19.7 1.6 3.7 20.6 1.5 4.0
47
60 17.4 1.3 3.8 18.4 1.3 4.1 19.3 1.3 4.4
70 16.3 1.4 3.5 17.3 1.0 5.6 18.3 1.3 4.1
80 15.2 1.4 3.1 16.3 0.7 7.0 17.3 1.4 3.7
40
60 15.5 1.3 3.6 16.4 1.2 3.9 17.3 1.2 4.2
70 14.5 1.3 3.2 15.3 1.3 3.5 16.0 1.3 3.8
80 13.4 1.3 2.9 14.1 1.3 3.1 14.8 1.3 3.3
30
60 13.2 1.2 3.2 13.8 1.2 3.4 14.3 1.2 3.6
70 12.1 1.2 2.9 12.7 1.2 3.1 13.4 1.2 3.3
80 10.9 1.3 2.5 11.7 1.2 2.8 12.5 1.2 3.0
17
60 9.6 1.1 2.5 10.0 1.1 2.6 10.4 1.1 2.8
70 8.7 1.2 2.2 9.0 1.1 2.3 9.3 1.1 2.4
80 7.8 1.2 1.9 8.0 1.2 2.0 8.2 1.2 2.1
10
60 8.4 1.2 2.1 8.9 1.1 2.3 9.5 1.1 2.5
70 7.5 1.2 1.9 8.0 1.1 2.1 8.5 1.1 2.2
80 6.5 1.2 1.6 7.0 1.2 1.8 7.5 1.1 1.9
NOTE: ALL CAPACITIES ARE NET (KBTUH) WITH INDOOR FAN HEAT ALREADY DEDUCTED AT 1250 BTUH/1000 CFM.
Air Handler Coil
T.C. S.C. KW
MA08B FC/MC18B 1.00 1.00 1.00
AHP18 – 1.00 0.99 0.98
F*FP024 – 0.99 0.99 0.98
MV12B FC/MC18B 0.97 0.94 0.91
AV24 – 0.97 0.94 0.91
– HC18 0.99 1.01 1.00
Variable Speed
Furnace *
Coil
T.C. S.C. KW
(F,L)L8VA12 FC/MC/PC18A 0.97 0.93 0.91
FL9VA12 FC/MC/PC18A 0.98 0.95 0.93
FL9(C,V)B12 FC/MC/PC18B 0.97 0.94 0.91
(F,L)L8VA12 HC18 0.98 0.95 0.93
FL9VA12 HC18 0.97 0.93 0.91
