York E*BD-(T User Manual

246819-BTG-H-0208
Unitary Products Group 3
Additional R-22 Charge / Orifice Size for Various Matched Systems - 1 Phase
Outdoor Unit EABD-F018S EABD-F024S EABD-F030S EABD-F036S EABD-F042S EABD-F048S EABD-F060S
Required TXV 1TVM2A1 1TVM2A1 1TVM2A1 1TVM2A1 1TVM2C1 1TVM2C1 1TVM2C1
Factory Charge, lbs-oz 7 - 1 6 - 9 8 - 9 8 - 7 8 - 7 12 - 8 16 - 7
Indoor Coil
1,2
Additional Charge, Oz
FC/MC/PC/UC18A2A 0––––––
FC/MC/PC/UC18B2A 0––––––
FC/MC/PC/UC24A2A –0–––––
FC/MC/PC/UC24B2A –0–––––
FC/MC/PC/UC30A2A –0–––––
FC/MC/PC/UC30B2A –0–––––
FC/MC/PC35B2A ––09–––
FC/MC/PC35C2C ––09–––
FC/MC/PC/UC42B2C ––09–––
FC/MC/PC/UC42C2C ––09–––
FC/MC/PC/UC48C2C – – – 9 14 – –
FC/MC/PC/UC48D2C – – – 9 14 – –
FC/PC/UC60C2C –––––77
FC/MC/PC/UC60D2C –––––77
MC61D2C –––––77
HC18A2A 0––––––
HC30A2A –0–––––
HC36B2A ––0––––
HC42C2C –––9–––
HC60C2C –––––77
HD24A2A –0–––––
HD36B2A ––09–––
HD48C2C – – – – 14 – –
HD60D2C –––––77
AHP18B2A 0––––––
AHP24B2A –0–––––
AHP30B2A ––0––––
AHP36C2A –––9–––
AHP42C2C –––9–––
AHP/SHP48D2C – – – – 14 7 –
AHP/SHP60D2C –––––77
AV24B2A 00–––––
AV36C2A ––09–––
AV/SV48D2C – – – – 14 7 –
AV/SV60D2C ––––––7
FC/MC/PC/UC18A3X 0––––––
FC/MC/PC/UC18B3X 0––––––
FC/MC/PC/UC24A3X –0–––––
FC/MC/PC/UC24B3X –0–––––
FC/MC/PC/UC30A3X –0–––––
FC/MC/PC/UC30B3X –0–––––
FC/MC/PC35B3X ––09–––
FC/MC/PC35X3X ––09–––
FC/MC/PC/UC42B3X ––09–––
FC/MC/PC/UC42X3X ––09–––
FC/MC/PC/UC48C3X – – – 9 14 – –
FC/MC/PC/UC48D3X – – – 9 14 – –
FC/PC/UC60C3X –––––77
FC/MC/PC/UC60D3X –––––77
MC61D3X –––––77
HC18A3X 0––––––
HC30A3X –0–––––
HC36B3X ––0––––
HC42C3X –––9–––
HC60C3X –––––77
