York MC62D3XC1 - Horizontal Duct Type Cooling Capacity; Uncased Upflow Cooling Capacity

813517-YTG-E-0114
4 Johnson Controls Unitary Products
COOLING CAPACITY - Coil Only
1
MODEL
RATED
CFM
ENTERING
AIR F
(Dry/Wet Bulb)
MBH @ Evaporator Temperature and Corresponding Pressure °F/ PSIG
35 / 61.5 40 / 68.5 45 / 76.0 50 / 84.0
HORIZONTAL DUCT TYPE
HD24S 815
85/72 35.3 32.4 28.7 24.9
80/67 32.6 29.4 26.0 22.5
75/62 26.7 23.7 20.5 17.2
70/57 21.7 18.8 15.7 12.3
HD36S 1192
85/72 57.9 52.7 47.1 41.5
80/67 46.4 41.1 35.9 30.4
75/62 36.2 30.4 26.5 24.7
70/57 31.1 28.7 26.5 24.7
HD48S 1610
85/72 83.4 71.7 59.7 47.1
80/67 66.8 56.1 45.6 34.9
75/62 52.1 41.5 33.7 28.3
70/57 44.7 39.2 33.7 28.3
HD60S 2100
85/72 133.0 112.4 90.9 69.2
80/67 106.5 87.9 69.4 50.0
75/62 83.0 65.0 51.3 41.1
70/57 71.2 61.4 51.3 41.1
1 See Condensing Unit or Heat Pump Technical Guide for Total Cooling Capacity and Sensible Capacity.
COOLING CAPACITY - COIL ONLY
1
1 See Condensing Unit or Heat Pump Technical Guide for Total Cooling Capacity and Sensible Capacity.
Model Coil Rated CFM
Entering Air °F
(Dry/Wet Bulb)
MBH@ Evaporator Temperature and Corresponding Pressure °F / PSIG
35 / 61.5 40 / 68.5 45 / 76.0 50 / 84.0
Uncased Upflow
UC18(A,B) 600
85/72 23.3 21.3 19.0 17.5
80/67 21.5 19.5 17.3 14.9
75/62 17.7 15.6 13.5 11.4
70/57 14.4 12.4 10.4 8.0
UC24(A,B) 800
85/72 27.4 25.0 22.3 19.4
80/67 25.3 22.9 20.3 17.5
75/62 20.8 18.4 15.9 13.4
70/57 16.9 14.6 12.2 9.4
UC30(A,B) 1000
85/72 35.2 32.0 28.6 24.8
80/67 32.4 28.6 25.3 21.9
75/62 26.6 23.6 21.5 18.7
70/57 25.2 22.7 20.2 17.6
UC36A 1150
85/72 46.8 42.7 37.9 33.0
80/67 43.1 39.2 34.9 30.4
75/62 35.3 32.1 28.6 24.9
70/57 33.3 26.9 26.9 23.4
UC36(B,C) 1200
85/72 49.3 44.9 39.9 34.7
80/67 45.4 41.3 36.7 32.0
75/62 37.2 33.8 30.1 26.2
70/57 35.0 28.3 28.3 24.6
UC42(B,C) 1400
85/72 86.7 73.0 59.2 44.9
80/67 69.4 57.2 45.2 33.1
75/62 54.0 42.3 33.4 26.8
70/57 46.4 40.0 33.4 26.8
UC48(C,D) 1600
85/72 62.4 56.8 50.5 44.4
80/67 57.4 53.2 46.5 40.5
75/62 47.1 42.8 38.1 33.2
70/57 44.3 40.3 35.8 31.2
UC60(C,D) 1800
85/72 95.4 82.1 68.4 54.0
80/67 76.4 64.1 52.2 39.9
75/62 59.6 47.4 38.6 32.4
70/57 51.2 44.8 38.6 32.4
