York YCJD48 - Page 5

840569-YTG-B-1012
Johnson Controls Unitary Products 5
— = Not applicable.
MA Modular Air Handlers use Coil Only Ratings
YCJD42S41S2(H)(E)
AHE42D 24.5 – 1385 42.0 30.6 14.25 12.00
AHE48D 24.5 – 1385 42.0 30.4 14.00 12.00
AHE60D 24.5 – 1390 42.0 31.0 14.50 12.00
AHR42C 21.0 – 1485 42.0 30.8 13.00 11.00
AHR48D 24.5 – 1320 41.0 28.8 13.00 11.00
AHR60D 24.5 – 1350 42.0 30.2 13.00 11.00
AHV42D 24.5 – 1385 42.0 30.2 13.75 11.75
AHV48D 24.5 – 1300 41.5 29.1 14.00 12.00
AHV60D 24.5 – 1340 42.0 30.2 14.00 12.00
AV*48 24.5 – 1385 42.0 30.4 14.25 12.00
AV*60 24.5 – 1360 42.0 30.4 14.25 12.00
MV16C 21.0 FC/MC43C 1380 42.0 30.2 14.00 12.00
MV16C 21.0 FC/MC48C 1400 42.0 30.4 13.75 11.75
MV16C 21.0 FC60C 1400 42.0 30.0 13.75 11.50
MV20D 24.5 FC/MC48D 1470 42.0 31.0 14.25 12.00
MV20D 24.5 FC/MC60D 1400 42.0 30.2 14.00 11.75
MV20D 24.5 FC/MC62D 1400 42.0 30.8 14.00 12.00
MV20D 24.5 FC64D 1400 42.0 30.8 14.50 12.25
MX16C 21.0 FC/MC43C 1365 42.0 30.2 14.25 12.00
MX16C 21.0 FC/MC48C 1390 42.0 30.2 14.25 12.00
MX16C 21.0 FC60C 1420 42.0 30.0 14.00 12.00
MX20D 24.5 FC/MC48D 1415 42.0 30.2 14.25 12.00
MX20D 24.5 FC/MC60D 1470 42.0 30.8 14.25 12.00
MX20D 24.5 FC/MC62D 1470 42.0 31.6 14.50 12.25
MX20D 24.5 FC64D 1470 42.0 31.6 14.75 12.50
YCJD48S41S1(H)(E)
AHE48D 24.5 – 1600 47.0 34.6 13.75 11.50
AHR48D 24.5 – 1610 48.0 34.6 13.00 11.00
AHV48D 24.5 – 1585 47.5 34.0 13.25 11.50
AHV60D 24.5 – 1570 48.0 35.0 13.50 12.00
AV*48 24.5 – 1625 48.0 35.0 13.50 12.00
AV*60 24.5 – 1560 48.0 35.0 13.50 12.00
MV16C 21.0 FC/MC48C 1600 48.0 35.0 13.50 12.00
MV16C 21.0 FC60C 1625 47.5 34.6 13.50 11.50
MV20D 24.5 FC/MC48D 1600 48.0 35.0 13.50 12.00
MV20D 24.5 FC/MC60D 1600 48.0 35.0 13.50 12.00
MX16C 21.0 FC/MC48C 1685 48.5 35.6 13.75 11.50
MX20D 24.5 FC/MC48D 1525 48.0 34.2 14.00 11.75
MX20D 24.5 FC/MC60D 1585 48.5 34.6 14.00 12.00
YCJD60S41S1(E)
AHE60D 24.5 – 1835 58.5 39.8 13.50 11.50
AHR60D 24.5 – 1870 57.0 38.5 13.00 11.00
AHV60D 24.5 – 1635 57.0 38.5 13.50 11.50
AV*60 24.5 – 1730 58.0 39.0 13.50 11.00
MV20D 24.5 FC/MC60D 1800 57.0 38.5 13.00 11.00
MV20D 24.5 FC/MC62D 1800 57.0 38.5 13.00 11.00
MV20D 24.5 FC64D 1855 57.0 39.0 13.75 11.50
MX20D 24.5 FC/MC60D 1780 57.5 38.8 13.75 11.50
MX20D 24.5 FC/MC62D 1795 58.0 38.8 14.00 11.75
MX20D 24.5 FC64D 1795 58.5 39.8 14.50 12.00
Rated in accordance with DOE test procedures (Federal Register 12-27-79 and 3-18-88) and ANSI/AHRI Standard 210/240.
Cooling MBH based on 80°F entering air temperature, 50% RH (Relative Humidity), and rated air flow.
EER (Energy Efficiency Ratio) is the total cooling output in BTUs at 95°F outdoor ambient divided by the total electric power in watt-hours at those conditions.
SEER (Seasonal Energy Efficiency Ratio) is the total cooling output in BTUs during a normal annual usage period for cooling divided by the total electric power input in
watt-hours during the same period.
1. MC coils available with a factory installed horizontal drain pan. See price pages for specific model number.
COOLING CAPACITY - With Air Handler Coils (Continued)
UNIT
MODEL
AIR HANDLER
COIL
MODEL
1
COOLING
MODEL WIDTH
RATED
CFM
NET MBH
SEER EER
TOTAL SENS.
13 SEER AC WITH AIR HANDLERS
