YORKVILLE PS10P - M1523 Component Reference List

M1523 Parts Reference List 1/22/2015
RE
F
YS # Description
J1 4090 1/4IN &XLR PCB MT VERT COMBO NCJ6-
V
J2 4100 XLR MALE PCB MT VER
T
J4 4063 1/4IN ISO JCK PCMT VT STER RT SWT
J5 3466 RCA DUAL PCB MT VERT GOLD 24MM
J6 4010 XLR FEML PCB MT VERT 24MM AA-SERIE
S
K1 3696 RELAY 1C 02AMP DC24 006MA PC-S
LD1 6405 RED 3MM LED 2V1 20MA DIFFUSD
LD2 6400 YEL 3MM LED 2V1 20MA DIFFUSD
LD3 6408 GRN 3MM LED 2V2 20MA DIFFUSD
P1 4459 _10K B LIN 9MM DET HI TORQ P32
P2 4459 _10K B LIN 9MM DET HI TORQ P32
P3 4459 _10K B LIN 9MM DET HI TORQ P32
R101 6543 48R 265V RESETTABLE THERMISTOR PTC
S1 3522 DPDT MINI PC VERT SNP AL
T
S8 3522 DPDT MINI PC VERT SNP AL
T
S9 3522 DPDT MINI PC VERT SNP AL
T
W1 4168 04 CIR DUAL ROW HDR HT 0.1 RA
W2 4166 06 CIR DUAL ROW HDR HT 0.1 RA
W3 4019 10 CIR SOCKT DIL VT 0.1
