STEP6
Align the holes of the folding tube with the holes on the vehicle’s
2’’ hitch receiver, then connect the two parts as shown below.
Place an M16 Shockproof Bolt (16), through the φ16 Spring
Washer (17), φ16 Flat Washer (18) and the aligned holes. Secure
the bolt in place with the φ3.8 pin (15), making sure to place the
pin through the holes on the bolt.
The diameter of lock beam
should be less than 7mm.
The lock is not included.
