YOWZA BOCA TREADMILL
STEP1
ASSEMBLY
STEP1-A). Rotate the Uprights up to vertical position.
STEP1-B). Using the Washer (826) and M8x58mm Bolt (824) to secure the
upright to frame by Allen wrench (A).
STEP1-C). Using the Curve washer∮8.5X20.5X2 (808) and Button head
inner hexagon Bolt M8X18(810) to secure the upright to frame by Allen
wrench (A).
808
X2
810
X2
826
X2
824
X2
