English
terminal.
Connect the POSITIVE (red) clip from the battery charger to
the POSITIVE (POS, +) ungrounded post of the battery.
Connect the NEGATIVE (black) clip to the vehicle chassis or
engine block away from the battery. Do not connect the clip to
the vehicle chassis or engine block sheet-metal body parts.
Connect to a heavy gauge metal part of the frame or engine
block.
Connect the NEGATIVE (black) clip from the battery charger
to the NEGATIVE (NEG, -) ungrounded post of the battery.
Connect the POSITIVE (red) clip to the vehicle chassis or
engine block away from the battery. Do not connect the clip to
the carburetor, fuel lines or sheet-metal body parts. Connect
to a heavy gauge metal part of the frame or engine block.
Connect the AC supply cord to the electrical outlet for
processing the charging.
A SPARK NEAR BATTERY MAY CAUSE BATTERY
EXPLOSION. TO REDUCE RISK OF A SPARK NEAR
BATTERY:
--Check polarity of battery posts. POSITIVE (POS, P, +)
battery post usually has a larger diameter than
NEGATIVE (NEG, N, –) post.
--Attach at least a 60 CM-long 6-gauge (AWG) insulated
battery cable to NEGATIVE (NEG, N, –) battery post.
--Do not face battery when making final connection.
--POSITION YOURSELF AND THE FREE END OF CABLE AS
G WHEN BATTERY
IS
OUTSIDE VEHICLE
A POSITIVE-GROUNDED
A NEGATIVE-GROUNDED
