When the charger is being used, it shows LED lights as follows,
indicating the status of the charging.
NO AC Power (all lights off)
There is no AC power applied. Check the AC end.
STAND BY (green blinking only)
The clamps are not connected to battery properly.
CHARGING (green & red lit)
The charger is charging the battery.
DEEPLY DISCHARGED BATTERY (yellow
blinking, green & red lit)
It takes more time to charge a deeply discharged
battery.
The indication goes to “yellow (defective
battery)” after 36 hours’ charging.
DEFECTIVE BATTERY (yellow lit only)
The battery cannot hold a charge.
Immediate replacement is recommended.
75% CHARGED (green lit & red light
blinking)
The battery is 75% charged and ready for load test
or can be returned to serve.
FULLY CHARGED (green lit only)
The battery is fully charged. The charger will shift to the
maintenance mode.
