Yudian AI-218 User Manual

Yudian (H.K.) Automation Technology Co. Ltd.
Website: http://www.yudian.us http://www.yudian.com.hk
Email: sales@yudian.com.hk
Tel: +852-2770 8785 Fax: +852-2770 8796
3. (Part 3 and 4) indicate the module installed in OUTP and AUX sockets.
Allowed modules in each socket are as below:
Allowed Type
Module Socket
N
L
L0/L1
L5
G
3. OUTP (main output)
√
√
4. AUX (Auxiliary output)
√
√
√
N (or none) no module installed
L Relay contact output module (Capacity: 5A/250VAC, normal open)
L0/L1 Relay contact output module (Capacity: 2A/250VAC, normal open/normal close, spark
absorption at normal open, support AU1 alarm output)
L5 Dual relay output module Output module (Capacity: 2A/250VAC, normal open, support AU1 and
AU2 alarm output)
G SSR voltage output module (30mA/5VDC)
* D1-sized controller is fixed to relay output (L) or SSR output (G) and no module option provided.
II. TECHNICAL SPECIFICATION
1. Input type : K, S, R, E, J, N (thermocouples); Pt100 (resistance temperature detector)
2. Instrument Input range : K (0~1300℃), S (0~1700℃) , R (0~1600℃), E (0~1000℃), J (0~1200℃),
N (0~1300℃), Pt100 (-200 ~ +800)℃
3. Measurement accuracy : 0.3%FS±1℃ or 0.3%FS±0.1℃
4. Control mode:
On-off control mode, or
PID control with auto-tuning.
5. Type of Alarm: High limit alarm, Lower limit alarm, Deviation High Alarm and Deviation Low Alarm
6. Power supply voltage rating: 100-240VAC, -15%, +10% / 50-60Hz.
7. Power consumption: ≤3W
8. Ambient temperature: -10~+60℃, Humidity: 0~90%RH
