LED
Light-Emitting Diode
LTE
Long Term Evolution
NC
Not Connected
PCB
Printed Circuit Board
PCM
Pulse Code Modulation
PDU
Protocol Data Unit
PMU
Power Management Unit
PPP
Point-to-point protocol
QPSK
Quadrature Phase Shift Keying
RF
Radio Frequency
RoHS
Restriction of the Use of Certain Hazardous Substances
SMS
Short Message Service
TIS
Total Isotropic Sensitivity
TVS
Transient Voltage Suppressor
TX
Transmitting Direction
UART
Universal Asynchronous Receiver-Transmitter
UMTS
Universal Mobile Telecommunications System
USIM
Universal Subscriber Identity Module
USSD
Unstructured Supplementary Service Data
VSWR
Voltage Standing Wave Ratio
WCDMA
Wideband Code Division Multiple Access
WWAN
Wireless Wide Area Network
8.3 Encoding
Table 8-2 Maximum HSDPA rate
HSDPA device category
Max data rate(peak)
Modulation type
Category 1
1.2Mbps
16QAM,QPSK
Category 2
1.2Mbps
16QAM,QPSK
Category 3
1.8Mbps
16QAM,QPSK
Category 4
1.8Mbps
16QAM,QPSK
Category 5
3.6Mbps
16QAM,QPSK
