ZALMAN S4 User Manual

• Pre-Installed rear 120mm fan
• Pre-Installed front 120mm fan
1) Mounting the front radiator
Radiator 120mm / 240mm
5. Mounting the PCI-E(VGA) card
7. Mounting the 2.5" SSD / HDD
8. Mounting the radiator
PSU / VGA
Бұрандалар x 2
6. Mounting the 3.5" and 2.5" SSD / HDD
2. SSD
1. HDD
HDD Бұрандалар
9. Pre-Installed Fan(s)
2) Mounting the rear radiator
Radiator 120mm
SSD / MB
Бұрандалар
SSD / MB
Бұрандалар x 4

ZALMAN S4 Specifications

General

Motherboard Support	ATX, Micro-ATX, Mini-ITX
Material	Steel, Plastic
Drive Bays	2 x 3.5", 2 x 2.5"
Expansion Slots	7
Pre-installed Fans	1 x 120mm rear fan
Maximum GPU Length	315 mm
Maximum CPU Cooler Height	160 mm
Maximum PSU Length	160mm
Type	Mid Tower
Front I/O Ports	1 x USB 3.0, 2 x USB 2.0, Audio In/Out
Cooling Support	Front: 2 x 120mm, Rear: 1 x 120mm, Top: 2 x 120mm
