Z11 Series
Installation
(1) Side Panel Removal
3
①
②
(2) Motherboard Installation
ATX Board
or
m-ATX Board
There are 4 Stand Offs preinstalled. Please refer to the diagrams below for
additional Stand Off positions (based on motherboard type).
Stand-Off
B Bolt
