USER MANUAL
read these warnings and precautions carefully
and follow them while using the device. Unless
stated otherwise, the term “device” means the
device and its accessories.
When storing, carrying and using the device,
keep it dry and protect it from collision with
other objects. Do not disassemble the device.
In an event of a malfunction, contact an autho-
rized service repair shop for assistance or re-
pairs. Neither any organization or an individual
is allowed to change the mechanical, safety
and performance parameters of the device
without permission. When using the device,
comply with all applicable laws and regulati-
ons and respect the rights of others.
Requirements for the environment, in which
the device is used. Keep the device away
from heat and re sources such as heaters or
candles. Keep the device away from electro-
nic devices that produce strong magnetic or
electric elds, such as microwave ovens or ref-
rigerators. Place the device on a stable surface.
Keep the device in a cool and well-ventilated
indoor environment. Never expose the device
to direct sunlight. During charging, the device
should be in an ambient temperature of 0°C to
35°C. When using a battery-powered device,
the ambient temperature should range within
0°C and 35°C. Do not place any objects (such as
a candle or water container) on the device. If
an object or liquid enters the device, stop using
the device immediately, turn it o, disconnect
all connected cables, and then contact an
authorized repair shop.
During a thunderstorm, turn o the device and
then disconnect all connected cables from the
device to protect it from a damage caused by
the lightning.
SAFETY DURING TRAVEL
Local laws and regulations must be complied
with when using the device. In addition, if
you use the device while driving, follow these
instructions: Focus on driving. Your primary
responsibility is to drive safely. Radio frequen-
cy (RF) signals can adversely aect electronic
systems in motor vehicles. Do not place the
device on an air bag or in an area where the
air bag is deployed in a motor vehicle. Failure
to do so could result in a device damage due
TECHNICAL PARAMETERS
• Battery: capacity 8.8Ah, LI-ION.
• 2-level protection against overcharging and
discharging.
• Short circuit protection and over-voltage
protection.
• RPM: 900–3,500
• The electronics are secured against overhea-
ting.
• Regulation of light intensity according to the
surroundings.
• Connector: USB-C max 12V / 5A.
• USB-C standards: PD3.0 / PD2.0 / QC3.0 /
QC2.0 / FCP / PE2.0 / PE1.1 / SFCP.
• Adapter: QC3.0, 12V / 1.5A.
• The device can be used as a PowerBank in
an emergency.
• Motor: max 3,500rpm, 30W.
TROUBLESHOOTING:
PrimerCube does not work, the display does
not respond – connect the PrimerCube to the
original charger (regardless of the battery sta-
tus on the display) and charge at least 3 hours.
Then use a paper clip – there is a small hole on
the PrimerCube next to the charging connector
– the reset button. Press the reset button for 3
seconds using a paper clip with caution. Then
your PrimerCube gets to the factory settings
and everything should work smoothly again.
Then charge your PrimerCube batteries with
the original charger to 100%
For other problems, contact our technical sup-
port: info@primercube.eu
FIRE SAFETY
If your device is extremely hot or smells, do not
attempt to remove the battery. If you detect
smoke coming from your device, clear the area
around it. Sprinkle the re with sand or use an
approved re extinguisher, or cover it with a
reproof container. Never use water to extin-
guish, as it may react with lithium and cause a
re. If you can move the device safely, place it
in a reproof or well-ventilated area and wait
until it cools completely. Therefore, in case
of any doubts, turn o the device, place it in
a reproof container and get it repaired in an
authorized repair shop.
WARNINGS AND PRECAUTIONS
Use the device correctly and safely - therefore,
ENGLISH
The timer can be activated with the EN button.
After pressing the EN button, you can see that
the T1 position is displayed in asolid dark
rectangle. This means that the set timer is acti-
ve and the PrimerCube is switched on and o
at the required time.
The deactivation of this function – timer – can
be set by pressing the DIS button. After deacti-
vation, the T1 value is displayed without abor-
der in asmaller black cube.
After the time interval of 5 minutes elapses,
during which the PrimerCube has not been
active, the device switches to the STANDBY
mode, i.e. the sleep mode. In this o mode,
the internal battery can be maintained fully
charged for about 1 month. Preset programs
are saved in the device‘s memory because
the EEPROM memory does not depend on the
battery charging activity.
If the battery level drops below 5 %, the
PrimerCube will automatically turn o and
OFF will appear on the display. In this case,
connect the PrimerCube to the power supply
source using a charging cable / adapter and
charge for at least 8–10 hours.
A button with the „lock“ symbol is located in
the lower right corner of the display. Use this
button to LOCK. When this function is acti-
ve, the touch screen closes securely and no
settings can be changed on it; neither inciden-
tally nor intentionally.
8: On/O
After activating the desired program by pre-
ssing the RUN button, the in-built rotary mo-
tor spins. The active operation of the device
motor is indicated on the display by the M
letter in circle. At the same time, during the
operation of the device, the in-built red LED
above the display lights up. Thanks to this, it is
easy to check the device activity even in entire
darkness.
LEDs control the luminous intensity according
to the ambient light value. Thus, when in com-
plete darkness, the luminosity of LEDs dims to
a minimum within a few minutes after start-up
so that the user is not disturbed, for example
during sleep.
Note Example: After starting the M1 program,
the display will show the RPM speed value
and the remaining application time until the
end of the program is displayed to the right
of the RPM speed. After this application time
elapses the PrimerCube is switched o. The
picture shows the remaining application time:
58 minutes. The LOCK function is not active.
The lock is open.
If the user wants to stop the program before
the remaining application time has elapsed,
press the STOP button on the display.
