20
English
15. Technical specifications (continued)
General
PARAMETER TEST CONDITION MIN TYP MAX
UNIT
Rated voltage (Un)
Phase-Neutral 207 230 253
V
Phase-Phase 360 400 440
Rated current (In) 32 A
Rated frequency 50 Hz
Standby power consumption 2 W
Ambient operating temperature -30 40
o
C
Maximum charging power TN 1 phase @ 32 A 7.4 kW
Protection class I
Overvoltage category III
Connectivity
PROTOCOL SUPPORTED STANDARDS
4G LTE Cat M1
Wi-Fi 802.11b/g/n (2.4 GHz)
Bluetooth Bluetooth v4.2 (BR/EDR/BLE)
RFID
ISO/IEC 14443 A (Type A, 13.56 MHz)
ISO/IEC 15693 Type A (Mifare Classic, 13.56 MHz)
OCPP 1.6J Core (cloud to cloud)
Integrated energy meter
PARAMETER TEST CONDITION MIN TYP MAX
UNIT
Accuracy Line voltage, current, and power factor +/-3 %
