ZAPTEC Go Installation Manual

9
English
5. Electrical connection
PE N L
PE N L
PE L1 L2 PE L1 L2
Max
6 mm
2
Max 12 mm
Click!
Connect all wires and firmly press down
all levers as illustrated. When the wires are
safely attached, replace the terminal cover
and turn on the circuit breaker.
Ferrules are optional.
Electrical wire dimensions

ZAPTEC Go Specifications

General

Type	Electric Vehicle Charger
Charging Power	22 kW
Weight	1.3 kg
Protection Rating	IP54
Charging Standard	IEC 61851-1
Maximum Charging Power	22 kW
Protection Class	Class I
Current Output	32A
Connectivity	Wi-Fi, Bluetooth
Operating Temperature	-30°C to +40°C
Input Voltage	230/400V AC
Cable Length	Not included
