Technical specifications
Mechanical and installation
PARAMETER TEST CONDITION MIN TYP MAX
UNIT
Dimensions H: 242
W: 180
D: 75
mm
Weight 1.3 kg
Altitude 2000 m
Input wire cross section 1.5 6 mm
2
Input cable diameter 9 18,5 mm
Degree of protection IP54
Charging mode Mode 3, case B
Mechanical strength IK08
Pollution degree Installation environment 4
Support for ventilation According to EN IEC
61851-1 6.3.2.2
No
Access According to EN IEC
61851-1 5.4
Restricted and non-restrict-
ed access
