ZBM MINI OTDR - Specifications; Buttons Description

3
1. Specifications
Model
OT6109S
Wavelength
1310nm or 1550nm
Type of fiber
9/125um SM Fiber
Connector
FC,SC/PC
Dynamic Range
22dB
Pulse Width
5ns~ 8000ns,Auto
Measurement
m
Event blind zone
3m
Attenuation blind
10m
Range accuracy
±（1m+2×10-4×distance）
OPM
-50~+26dBm
850/1300/1310/1490/1550/1625nm
VFL
≥10mW
Optical Light Source
1550nm
Event Map Function
Yes
Power Supply
3pcs of Dry battery
Battery Work time
≥2000 times measure
Save Data
＞500
Work Temperature
-5~40℃
Save Temperature
-10~60℃
Humidity
0~85%（no condensation）
Net weight
300g
2.Buttons Description
1. : On / off key, when in power-on, short press switch to auto-off function ；long press about 3s off.
When the top right corner of LED show ，The instrument will automatically shut down for about 10
minus in the state of no key operation.
2. SCAN, Start OTDR module to test the fiber. Press about 6s, enter auto cycle test, press exit again.
3. ▲-View the previous measurement or choose previous option
4. ▼-View the next measurement or choose next option
5. ◄--View a measurement to the left or select an option to the left
6. ►-View a measurement to the right or select an option to the right
7. ENT select the confirm button or deselect
8. VFL light shows starting work
