1 INTRODUCTION
1.1 IWAC Display v3
IWAC Display v3 from Zennio is a KNX interface presented as an access control
system to rooms or other parts of the installation through reading ID cards.
The most notable features of this device are:
Access control to rooms using cards with NFC (Near Field
Communication) technology of MIFARE DESFire and MIFARE Classic
types.
2.4-inch OLED display with 128 x 64 pixels resolution.
Multilanguage.
Buzzer for an audible acknowledgement of user actions (with the possibility
of disabling it by object).
Encrypted communication with Securel v2 for door opening.
Communication with Z-Access for the management and monitoring of
accesses.
3 touch buttons, which can operate as individual control.
Possibility of locking / unlocking the touch panel through binary object.
Possibility of setting a press detection delay.
Two analogue/digital inputs (for motion detectors, temperature probes,
additional switches, etc.).
Heartbeat.
