1 4050-11110 HOUSING 1
2 4050-11150 CAP 1
3 4050-11210 JOINT 1
4 4050-11250 ABSORBER-F 1
5 4050-11260 ABSORBER-R 1
6 01252-30530 BOLT 4
7 01252-30630 BOLT 1
8 01252-30510 BOLT 1
9 T3113-11310 DRUM 1
10 06004-06202 BEARING 1
11 04065-03515 RING 1
12 04064-01510 RING 1
13 3544-11510 BOLT 4
14 T3113-12100 PIPE COMP 1
ø26x1500
15 3520-12213 SHAFT, spline ø7x7teeth 1
ø7x1536
16 6522-13000 GEARCASE ASSY 1
17 6522-13110 • GEARCASE 1
18 06000-06000 • BEARING 2
19 06000-06202 • BEARING 1
20 3130-13141 • SEAL 1
21 04065-03515 • RING, SNAP 1
22 01252-30510 • BOLT 1
23 3540-13212 • SHAFT 1
24 3540-13220 • GEAR 1
25 3544-13280 • WASHER 1
26 01643-31032 • WASHER 1
27 3540-13290 • BOLT 1 M10(L)
28 6522-13310 • PINION 1
29 06001-06000 • BEARING 1
30 3180-13330 • RING 1
31 04065-02612 • RING 1
32 3540-13260 • BOLT 1
33 0224-40610 • BOLT 1
34 6251-13240 • HOLDER(A) 1
35 3540-13251 • HOLDER(B) 1
36 6520-17100 HANGER ASSY 1
37 6520-17110 • HANGER 1
38 6520-17120 • CLAMP 1
39 6520-18130 • SPACER 1
40 0263-90525 • SCREW 1
41 T3112-12510 PLATE, name 1
42 T3112-12590 PLATE, number 1
43 6425-12552 PLATE, caution 1
44 T3112-14000 HANDLE ASSY 1
45 T3112-14110 • HANDLE 1
46 0263-90530 • SCREW 4
47 6489-24000 GUARD ASSY 1
48 6489-24110 • GUARD 1
49 6489-24200 • PLATE COMP 1
50 6489-24210 • • PLATE 1
51 6489-24220 • • BLADE 1
52 0277-10412 • • SCREW 1
53 6489-24120 • PLATE 1
54 01252-30516 • BOLT 4
55 01601-20513 • WASHER 4
56 3540-13283 COVER 1
57 6251-15910 COVER 1
58 T3300-17100 STRAP ASSY 1
59 6298-14343 SAW 1
60 T3112-18000 GRIP ASSY 1
61 K2300-000240 • GRIP (R) 1
62 K2300-000230 • GRIP (L) 1
63 K3200-000390 • CLAMP (A) 1
64 K3300-000010 • PLATE (A) 1
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
65 K3300-000020 • PLATE (B) 1
66 K5100-000240 • COLLAR 1
67 K5100-000220 • SPRING 1
68 K2300-000260 • SAFETY LEVER 1
69 K2300-000250 • THROTTLE LEVER 1
70 K3200-000400 • CLAMP (B) 1
71 K5100-000230 • SPRING 1
72 K5100-000210 • SPRING 1
73 K2300-000270 • PLATE 1
74 B1122-C2910H • SCREW 1
75 K2300-000280 • SWITCH 1
76 K5200-000090 • CORD 1
77 K5100-000270 • CABLE COMP 1
78 K5100-000201 • • THROTTLE CABLE 1
79 K5200-000130 • • SLEEVE 1
80 K2300-000390 • LID 1
81 B1176-090530 • SCREW 4
82
B1181-04054606
• NUT 4
83 T3113-91000 TOOL KIT 1
84 1030-91340 • DRIVER 1
85 3144-91160 • SOCKET 1
86 09007-00425 • WRENCH 1
87 09007-00528 • WRENCH 1
88 3540-91110 • BAR 1
89 T3115-93110 MANUAL 1
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
Fig.1 CUTTER GROUP
BC3401DLM
