1 4050-11110 HOUSING 1
2 4050-11150 CAP 1
3 4050-11210 JOINT 1
4 4050-11250 ABSORBER-F 1
5 4050-11260 ABSORBER-R 1
6 01252-30530 BOLT 4
7 01252-30630 BOLT 1
8 01252-30510 BOLT 1
9 T3113-11310 DRUM 1
10 06004-06202 BEARING 1
11 04065-03515 RING 1
12 04064-01510 RING 1
13 3544-11510 BOLT 4
14 T3113-12100 PIPE COMP 1
ø26x1500
15 3520-12213 SHAFT, spline ø7x7teeth 1
ø7x1536
16 6522-13000 GEARCASE ASSY 1
17 6522-13110 • GEARCASE 1
18 06000-06000 • BEARING 2
19 06000-06202 • BEARING 1
20 3130-13141 • SEAL 1
21 04065-03515 • RING, SNAP 1
22 01252-30510 • BOLT 1
23 3540-13212 • SHAFT 1
24 3540-13220 • GEAR, 1
25 3544-13280 • WASHER 1
26 01643-31032 • WASHER 1
27 3540-13290 • BOLT 1 M10(L)
28 6522-13310 • PINION 1
29 06001-06000 • BEARING 1
30 3180-13330 • RING 1
31 04065-02612 • RING 1
32 3540-13260 • BOLT 1
33 0224-40610 • BOLT 1
34 6251-13240 • HOLDER(A) 1
35 3540-13251 • HOLDER(B) 1
36 3530-14900 BRACKET ASSY 1
37 3540-14910 • BRACKET 1
38 3540-14920 • CAP-L 1
39 3540-14930 • CAP-U 1
40 3540-14140 • ABSORBER 2
41 3540-14150 • CLAMP 1
42 3540-14160 • CLAMP 1
43 01252-30525 • BOLT 6
44 01252-30530 • BOLT 4
45 3530-14171 • SPACER 2
46 6520-17100 HANGER ASSY 1
47 6520-17110 • HANGER 1
48 6520-17120 • CLAMP 1
49 6520-17130 • SPACER 1
50 0263-90525 • SCREW 1
51 T3113-12510 PLATE, name 1
52 T3113-12590 PLATE, number 1
53 6425-12552 PLATE, caution 1
54 6489-24000 GUARD ASSY 1
55 6489-24110 • GUARD 1
56 6489-24200 • PLATE COMP 1
57 6489-24210 • • PLATE 1
58 6489-24220 • • BLADE 1
59 0277-10412 • • SCREW 1
60 6489-24120 • PLATE 1
61 01252-30516 • BOLT 4
62 01601-20513 • WASHER 4
63 3540-13283 COVER 1
64 6251-15910 COVER 1
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
65 6220-17202 HARNESS ASSY 1
66 4050-17110 PROTECTOR 1
67 3540-93120 BAND 1
68 6298-14343 SAW 1
69 T3111-14300 HANDLE-L COMP 1
70 T3113-14100 HANDLE-R COMP 1
71 T3111-14110 • HANDLE-R 1
72 K6010-000550 • GRIP&LEV, COMP 1
73 K2200-000040 • • LABEL 1
74 K2300-000050 • • GRIP (L) 1
75 B1181-040545 • • NUT 1
76 K2300-000080 • • SWITCH 1
77 K5100-000030 • • SPRING 1
78 K5100-000040 • • SPRING 1
79 K2300-000090 • • HOLDER 1
80 B1122-C2910H • • SCREW, M3x10 2 Tapping
81 K5100-000020 • • SPRING 1
82 K2300-000070 • • LEVER 1
83 K5100-000010 • • SPRING 1
84 K2300-000060 • • LEVER 1
85 K1300-000060 • • PLUG 1
86 K5100-000050 • • SPRING 1
87 K2300-000040 • • GRIP (R) 1
88 B1111-A0530H • • SCREW, M5x30 1
89 B1122-C4220H • • SCREW, M4x20 5 Tapping
90 K5200-000070 • CORD 1
91 K5100-000130 • CABLE 1
92 K5200-000080 • TUBE 1
93 T3113-91000 TOOL KIT 1
94 1030-91340 • DRIVER 1
95 3144-91160 • SOCKET 1
96 09007-00425 • WRENCH 1
97 09007-00528 • WRENCH 1
98 3540-91110 • BAR 1
99 T3115-93110 MANUAL 1
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
Fig.2 CUTTER GROUP
BC3401DWM
