Fig.2 ENGINE GROUP
1 5500-12110 CYLINDER 1
2 5500-12211 GASKET,base 1
3 1850-12130 BOLT 2
4 5500-13162 INSULATOR 1
5 5500-13120 GASKET,insulator 1
6 5500-13130 GASKET,carburetor 1
7 00263-90520 SCREW 2
8 5580-15110 MUFFLER 1
9 01252-30550 BOLT 2
10 5500-15210 GASKET 1
11 5500-15220 PLATE 1
12 00263-90416 SCREW 1
13 5500-21100 CRANKCASE COMP 1
14 5500-21140 GASKET,case 1
15 06030-06001 BEARING 2
16 2169-21210 OIL SEAL 1
17 1850-21220 OIL SEAL 1
18 04065-02812 SNAP RING 1
19 01252-30530 BOLT 4
20 5600-41111 PISTON 1
21 1100-41210 RING 2
22 1101-41310 PIN 1
23 1260-41320 SNAP RING 2
24 1140-41330 BEARING 1
25 1101-41340 WASHER 2
26 5500-42001 CRANKSHAFT COMP 1
27 1650-43230 NUT 1
28 1000-43240 KEY 1
29 1400-51111 SHOE 2
30 1140-51250 SCREW 2
31 1970-51221 SPRING 1
32 1140-51230 WASHER 1
33 1970-51241 WASHER 1
34 5501-71110 ROTOR 1
35 5501-71201 COIL ASSY 1
36 5500-71220 • CORD,high 1
37 2616-71320 • CAP 1
38 1900-72111 CAP 1
39 1900-72120 SPRING 1
40 5500-72130 GROMMET 1
41 1260-71261 SPACER 2
42 3310-72150 BOLT 2
43 5500-75000 STARTER ASSY 1
44 5500-75100 • RECOIL ASSY 1
45 1850-75120 • • REEL 1
46 1850-75130 • • SPIRING,spairal 1
47 1850-75151 • • SCREW 1
48 1850-75160 • • ROPE 1
49 1140-75320 • • KNOB 1
50 5500-75170 • • TAPE 1
51 1850-75201 • PULLEY ASSY 1
52 1850-75221 • • RATCHET 1
53 1850-75230 • • SPRING 1
54 00263-90416 SCREW 4
55 5500-81002 CARBRETOR ASSY 1
56 1850-81450 • BODY ASSY 1
57 3306-81380 • • SCREEN 1
58 3356-81310 • • VALVE 1
59 1850-81270 • • SPRING 1
60 1850-81220 • • SCREW 1
61 3310-81250 • • PIN 1
62 3310-81230 • • LEVER 1
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
63 1850-81490 • BODY 1
64 1850-81520 • COVER 1
65 1751-81510 • PUMP 1
66 3310-81260 • DIAPHRAGM ASSY 1
67 1850-81470 • GASKET 1
68 1065-81420 • DIAPHRAGM 1
69 1065-81410 • GASKET 1
70 5500-81251 • JET 1
71 1751-81240 • O-RING 4
72 1751-81130 • RING 2
73 5500-81160 • WASHER 1
74 1881-81140 • SWIVEL 1
75 5500-81153 • VALVE ASSY 1
76 1752-81110 • SCREW 2
77 5500-81120 • BRAKET 1
78 1751-81180 • NUT 1
79 1918-81170 • SCREW 1
80 1881-81130 • RING 1
81 1850-81530 • SCREW 1
82 00263-90560 SCREW 2
83 1950-86120 CLIP 1
84 5500-82102 BODY ASSY 1
85 1970-82190 • SLEEVE 2
86 5500-82131 • PLATE 1
87 5500-82140 • LVEVER 1
88 2630-33610 • SCREW 1
89 5500-82171 ELEMENT 1
90 5600-82201 COVER ASSY 1
91 5500-82221 • KNOB 1
92 5500-82230 • RING 1
93 5501-31111 COVER 1
94 00263-90520 SCREW 4
95 5580-32111 COVER 1
96 1850-32160 SCREW 1
97 1900-31410 SCREW 2
98 5500-32210 GUARD 1
99 00263-90514 SCREW 1
100 1216-73110 SPARKPLUG 1 Champion RCJ-8Y
101 1852-72120 GROMMET 1
102 5500-73201 CORD COMP 1
103 1140-72231 CLAMP 1
104 5504-85001 TANK ASSY 1
105 5504-85201 • CAP ASSY 1
106 5500-85220 • • PACKING 1
107 3317-57242 • • STOPPER 1
108 5500-85602 • BREATHER ASSY 1
109 1950-86120 • • CLIP 1
110 5500-85300 • PIPE COMP 1
111 5500-85400 • FILTER ASSY 1
112 1260-85460 • CLIP 1
113 5500-85510 SCREW 2
114 1140-72231 CLAMP 1
115 5912-91120 LABEL,recoil 1
116 5500-91130 LABEL,cover 1
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
