4
1. Parts location
English
English
2. Specifications
Model HT2200 CHT2200
Type Reciprocating Reciprocating
single-sided dual blades double-sided dual blades
Dry weight 4.3(kg)/9.5(lbs)
Blade size 600(mm)/24(in) 550(mm)/22(in)
Blade pitch 35(mm)/1.38(in)
Transmission Centrifugal clutch, Cam-crank
Reduction ratio 4.33
Engine Type Air-cooled 2-stroke gasoline
Mode Zenoah G23LH
Displacement
22.5(cm
3
)/1.37(cu-in)
Max. output 0.68Hp(0.51kW)at 6500/min
-
1
(rpm)
Idle speed 2800
±
200/min
-
1
(rpm)
Fuel mixture(Gasoline 50
:
Oil 1)(when using ZENOAH genuine oil)
Carburetor Walbro Diaphragm type
Spark plug CHAMPION RCJ6Y
Fuel tank capacity 0.59(litter)/20.0(fl.oz)
Durability period 300(hrs.)
Specifications are subject to change without notice.
1. Right handle
2. Fuel tank
3. Starter
4. Left handle
5. Throttle lever
6. Ignition switch
7. Throttle Cable
8. Muffler
9. Blade
10. Front handle
11. Rear handle
