INSTALLATION
10
STEP 1
STEP 3
STEP 5
STEP 2
STEP 4
STEP 6 (also refer notes on pg. 16)
1. Remove all contents from box
2. Unscrew and remove bottom grease splash shield
1. Locate electrical connection box knock out from left
rear of hood and pry open with screwdriver
1. Cut out cabinet base opening if necessary. Refer
cut out dimensions previous page.
1. Reinforce cabinet base with 1x2 wood strips if
additional strengthening is required.
2. Unscrew and remove bottom grease splash shield
1. Install damper if required by local codes (not
provided), or install 6“ starting collar (green)**
1. Locate electrical connection box inside
2. Unscrew cover to reveal wiring
To Next Page
