BBV24C01AG Use, Care, and Installation Guide
Installation Instructions
► To prevent damaging the door or door gasket, make sure the door is open at least 90-degrees
when pulling shelves out of the rail compartment.
► The door opens to a maximum of 135 degrees with a door stop on the bottom hinge preventing the
door from opening further.
Removing the Wire or Glass Shelf
1. Open the door completely.
2. Remove all of the contents loaded on the
shelf, if applicable. Follow step 3 for wire
shelf removal and follow step 4 for glass
shelf removal.
3. For wire shelf: Pull the shelf out slightly,
gently lift the back, and slide it out to
remove the shelf.
4. For glass shelf: Place hand on the bottom
of glass shelf, gently lift the back, and
slide it out to remove the shelf.
