BETAPACK3 USER GUIDE
Zero88 Lighting Ltd, Usk House, Llantarnam Park, Cwmbran, Gwent NP44 3HD, U.K www.zero88.com
Tel: +44 (0) 1633 838088 (24hr Answer Phone) Fax: +44 (0) 1633 867880 Email: sales@zero88.com
73-682-00 IM8025Betapack3ManualIssue1_0.doc Page 6 of 7
Topset
Topset can be selected on a per channel or all channel
basis. On the Betapack3, Topset is applied as a limiting
(not scaling) value.
Select ‘Topset’ by cycling through the modes using the
‘Mode’ button.
Select required channel or ‘A’ for all channels, using the
‘Up & Down’ Arrows and press ‘Enter’, to confirm.
Now select the topset level you require, again using the
‘Up & Down’ Arrows and press ‘Enter’ to confirm and
return to the channel selection.
Note that if the law is set to ‘Switch’, the setting in
Topset will instead be used to determine the
switchpoint. The ‘Topset’ LED will flash in this case, to
indicate the setting being made.
Dimmer Laws
Three dimmer laws are available, which can be
selected per channel.
Select ‘Law’ mode using the ‘Mode’ button. Using the
‘Up & Down’ Arrows select the channel required, or ‘A’
for all channels. Press ‘Enter’ to confirm. Now select
the law you require, again using the ‘Up & Down’
Arrows and press ‘Enter’ to confirm and return to the
channel selection.
Output Law
Main Display
Normal
n
Switch
S
Linear
L
Note that if the law is set to Switch, the switchpoint can
be set in the ‘Topset’ menu.
Super User
The Betapack3 has a number of hidden functions,
located in the Super User Menu. The super user
menus can only be accessed from the Default mode
(no LEDs lit). To enter Super User press and hold the
‘Up & Down’ Arrows together and press and hold the
‘Mode’ button for 5 seconds. All the mode LEDs will
flash to indicate the Betapack3 is in super user mode.
The ‘Up & Down’ Arrows are used to cycle through the
various super user functions. Pressing the ‘Mode’
button at any point will revert to normal operation. If no
buttons are pressed after 20 seconds the unit will
automatically revert to normal operation.
Dimmer Lock/Unlock
Press the ‘Up & Down’ Arrows until the display shows
“LOC”. Press ‘Enter’ to confirm this action. The
Betapack3 will revert to the Default mode. Pressing the
‘Mode’ button now will only cycle between Manual
Control and Default Mode.
If Super User is entered when the Betapack3 is locked,
only the unlock function will be available. The display
will show “UNL”. To unlock the Betapack3, press and
hold the ‘Enter’ button for 5 seconds. The Betapack3
will unlock and exit super user returning to the Default
mode.
Resetting The Betapack3
Press the ‘Up & Down’ Arrows until the display shows
“rset”. Press ‘Enter’ to confirm. The display will flash
briefly to confirm this action. The Betapack3 will be
reset to its default settings, shown in the table below:
Set Up Parameter State
Manual Control Levels All Off
DMX Addresses Block patch at 001
DMX Fail Mode Hold Last State
Memory All Memories Cleared
Sequence All Sequences Cleared
Preheat Off (0%) for all channels
Topset 100% for all channels
Law Normal law for all channels
Switch law switchpoint 50% for all channels
Firmware Version
To identify which version of firmware is loaded in the
Betapack3, press the ‘Up & Down’ Arrows until the
firmware version is shown in the display (e.g. 01.00)
Press and hold the ‘Enter’ button for 1s, and the
Betapack3’s CPU serial number will be displayed.
Press the ‘Enter’ button again to return to the version
display. Note that the firmware version will also be
shown briefly on start up.
Internal Temperature
Press the ‘Up & Down’ Arrows until the temperature is
shown in the display, shown as xxxC, where xxx is the
temperature in Centigrade. The ‘Enter’ button has no
function in this mode.
