ZF 63 - Dipstick Removal; Breather Valve Removal; Output Flange Removal

3.2 DIPSTICK
Unscrew dipstick (item 1, Fig. 2-1) (counterclockwise)
and pull out of housing. Replace O-Ring if present
(check parts list section 11).
3.3 BREATHER VALVE
Unscrew breather valve (item 1, Fig. 3-1). Wash valve
in a detergent, let dry and dip in oil, then let oil drip off.
3.4 OUTPUT FLANGE
Lock output flange in swivel frame.
Unscrew hex head bolt (item 1, Fig. 4-1).
Remove disc (item 2, Fig. 4-1) and O-ring (item 3, Fig. 4-
1).
Screw hex bolt (item 1, Fig. 4-1) in again.
Place extractor on the transmission and pull output
flange (item 1, Fig. 4-2) off.
10
Repair Manual and Spare Parts List Section 3
1
FIG. 2 - 1
1
FIG. 3 - 1
1
2
3
4
FIG. 4 - 1
1
FIG. 4 - 2
