ZF 63 - Shifting Pressure Chart; Lube Oil Delivery Rate Chart

5. ADJUSTMENT DATA
5.1 SHIFTING PRESSURE
5.2 LUBE OIL DELIVERY RATE
27
Repair Manual and Spare Parts List Section 5
SHIFTING PRESSURE (bar)
DRIVING SPEED (rpm)
SHIFTING PRESSURE (psi)
MAX.
MIN.
400
350
300
250
200
150
100
50
0
500040003000200010000
0
10
20
30
5
15
25
500 1500 2500 3500 4500
22
21.5
ZF 63 A - ZF 63 - ZF 80 A; mechanical selector valve 23 bar p/n 3312 108 001
ZF 80-1 A - ZF 85 A - ZF 80 A (ZF 85 A DERIVATE VERSION); mechanical selector valve 26 bar p/n 3313 108 001
DELIVERY RATE ( /min)
DRIVING SPEED (rpm)
DELIVERY RATE (gal. /min)
7.39
6.86
6.33
5.80
5.28
4.75
3.69
0
500040003000200010000
0
10
20
30
MIN. ALL MODELS
7.91
4.22
3.17
2.64
2.11
1.58
1.05
0.53
500 1500 2500 3500 4500
5
15
25
ZF 63 A - ZF 63 - ZF 80 A; mechanical selector valve 23 bar p/n 3312 108 001
ZF 80-1 A - ZF 85 A - ZF 80 A (ZF 85 A DERIVATE VERSION); mechanical selector valve 26 bar p/n 3313 108 001
