Pos. Part number Old P/N Descrizione Description
Q.ta
Á
Note
Q.ty
1 3312 301 004 451892 Scatola Housing 1
2 0636 301 041 442373 Tappo Plug 1
3 0634 319 132 442135 Paraolio uscita Output shaft seal 1
4 3312 101 003 500484 Coperchio filtro completo Filter cover, assy. 1
5
I
. Coperchio filtro . Filter cover 1
6 0634 304 688 442731 . Guarnizione OR . O-Ring 1
7 0634 306 204 105542 Guarnizione OR O-Ring 1
8 0630 001 085 167010 . Rosetta . Washer 1
9 0636 101 475 320202 . Vite M8x30 . Screw M8x30 1
10 3312 301 007 438637 Filtro olio Oil filter 1
(2) old part number
11 3312 301 008 439653 Guarnizione Sealing washer 1
12 3312 199 031 463772 Filtro olio completo Oil filter, assy 1
13 0634 304 688 442731 . Guarnizione OR . O-Ring 1
14 0634 306 204 105542 . Guarnizione OR . O-Ring 1
15 3312 301 037 . Filtro olio . Oil filter 1
(2) new part number
16 3312 301 005 438948 Tubo aspirazione Suction pipe 1
3312 301 033 Tubo aspirazione con supporto Suction pipe with support 1
17 3312 301 013 439223 Piastra ritegno Retaining plate 1
18 0636 113 006 455079 Vite T.E. Hex head screw 2
(ritegno tubo aspirazione) (suction pipe retainer)
0636 015 020 Vite T.E. Hex head screw 2
(tubo aspirazione con supporto) (suction pipe with support)
19 0631 315 520 335817 Spina Locator pin 2
20 3312 301 002 451889 Coperchio Cover (housing) 1
3312 301 003 501352 Coperchio Cover (housing) 1
(1)
21 978.36.701.02 454913 Asta livello olio Oil dipstick 1
3312 201 002 500989 Asta livello olio + OR Oil dipstick + OR 1
22 0634 304 405 501211 . Guarnizione OR . O-Ring 1
(Asta livello olio) (Oil dipstick)
23 3311 301 002 442369 Valvola di sfiato Breather valve 1
24 3312 301 030 413883 Paraolio entrata Input shaft seal 1
25 0630 302 091 442371 Rosetta Washer 12
26 0636 010 550 442374 Vite T.E. Hex head screw 4
27 0636 015 227 442375 Vite T.E. Hex head screw 5
28 0636 010 572 442376 Vite T.E. Hex head screw 2
29 0636 015 386 452512 Vite T.E. Hex head screw 1
30 0636 113 006 455079 Vite T.E. Hex head screw 1
0636 015 020 Vite T.E. Hex head screw 1
31 0630 001 046 Rosetta Washer 1
32 3312 301 011 455053 Piastra Buffle plate 1
Ratio I=1.2; 1.6; 2.0
3312 301 012 458290 Piastra Buffle plate 1
Ratio I=2.5; 2.7
33 0636 113 006 455079 Vite T.E. Hex head screw 2
0636 015 020 Vite T.E. Hex head screw 2
34 0630 001 046 Rosetta Washer 2
35 3312 301 006 438963 Piastra Buffle plate 1
36 3312 301 001 Targhetta di identificazione Name plate 1
37 0630 001 085 167010 Rosetta Washer 1
38 0636 101 475 320202 Vite M8x30 Screw M8x30 1
Fino a matricola 10730G - Up to serial number 10730G
Da matricola 10731G - From serial number 10731G
(1) Only Ratio I=2.7 (also PCM) ; Ratio I=2.52 uprated version & ratio I= 2.52 (for PCM only)
(2) Fornito solo incluso nel kit filtro olio p/n 3312 199 031
Supplied only included in the oil filter kit p/n 3312 199 031
41
Repair Manual and Spare Parts List ZF 63 A FIG. 1
