Pos. Part number Old P/N Descrizione Description
Q.ta
Á
Note
Q.ty
1 3313 199 078 Assieme scatola Housing, assy. 1 up to s/n XXXXXR
3313 199 114 Assieme scatola Housing, assy. 1 from s/n XXXXXR
3313 301 009 . Scatola . Housing 1 up to s/n XXXXXR
3313 201 003 . Scatola con boccola flangiata . Housing with flanged bushing 1 from s/n XXXXXR
3313 301 022 . Tubo aspirazione con supporto . Suction pipe with support 1
0636 101 411 . Vite . Screw 1
3312 301 008 . Guarnizione . Gasket 1
2 0636 301 041 442373 Tappo M16x1,5 Plug M16x1.5 1
3 0634 319 104 448160 Paraolio uscita Output shaft seal 1
4 3312 101 003 500484 Coperchio filtro completo Filter cover, assy. 1
5 . Coperchio filtro . Filter cover 1
6 0634 304 688 442731 . Guarnizione OR . O-Ring 1
7 0634 306 204 105542 . Guarnizione OR . O-Ring 1
8 0630 001 085 167010 . Rosetta . Washer 1
9 0636 101 475 320202 . Vite M8x30 . Screw M8x30 1
10 3312 301 007 438637 Filtro olio Oil filter 1
(1) old part number
11 3312 301 008 439653 Guarnizione Gasket 1
12 3312 199 031 463772 Filtro olio completo Oil filter, assy 1
13 0634 304 688 442731 . Guarnizione OR . O-Ring 1
14 0634 306 204 105542 . Guarnizione OR . O-Ring 1
15 3312 301 037 . Filtro olio . Oil filter 1
(1) new part number
16 3313 301 022 Tubo aspirazione con supporto Suction pipe with support 1
17 0636 101 411 102879 Vite T.E. M6x16 Hex head screw M6x16 1
(fascetta tubo aspirazione) (suction pipe clamp)
18 3313 301 014 462997 Anello centratore Centering ring 1 up to s/n XXXXXR
19 0631 315 520 335817 Spina Locator pin 2
20 3312 301 030 413883 Paraolio entrata Input shaft seal 1
21 3311 301 002 442369 Valvola di sfiato Breather valve 1
22 3313 301 010 Coperchio Cover (housing) 1
23 3313 201 001 500993 Asta livello olio + OR Oil dipstick + OR 1
24 0634 304 405 501211 . Guarnizione OR (Asta livello olio) . O-Ring (Oil dipstick) 1
25 0630 302 091 442371 Rosetta Washer 14
26 0636 015 227 442375 Vite T.E. M10x35 Hex head screw M10x35 14
27 3312 301 017 469691 Tappo Plug 1
28 3312 301 001 Targhetta di identificazione Name plate 1
30 0630 001 085 167010 Rosetta Washer 1
31 0636 101 475 320202 Vite M8x30 Screw M8x30 1
(1) Fornito solo incluso nel kit filtro olio p/n 3312 199 031
Supplied only included in the oil filter kit p/n 3312 199 031
73
Repair Manual and Spare Parts List ZF 80 A - ZF 80-1 A FIG. 1
