Pos. Part number Old P/N Descrizione Description
Q.ta
Á
Note
Q.ty
1 3312 199 015 Distributore elettrico Electric selector valve 1
[
26 bar ON/OFF 26 bar ON/OFF
2 3312 308 069 Elettrovalvola ON/OFF 12V Solenoid valve ON/OFF 12V 2
3 0631 405 061 Tappo Dummy plug 1
4 0636 302 053 Tappo M10x1 Screw plug M10x1 1 Ma= 12 Nm
5 0634 801 302 Rosetta Washer 1
6 0636 309 007 Tappo Screw plug 1 Ma= 30 Nm
7 3316 117 001 Assieme connettore Connector kit 2
8 0636 101 727 Vite T.E. M8x40 Cap screw M8x40 6
9 0630 302 090 Rosetta Spring washer 6
10 3312 308 020 Guarnizione Gasket 1
[
Installare con 12 V - To be installed with 12 V power supply
81
Repair Manual and Spare Parts List ZF 80 A - ZF 80-1 A FIG. 4
